SHFP/SHFA/SHFE
Fine Chemical
Capsule Filters
PES, Nylon, PTFE, PP
| Availability: | |
|---|---|
| Quantity: | |
Ink Specific Capsule Filter - Engineered for Digital Printing & Ink Filtration
APPLICATIONS
• Industrial Marking & Coding: Filtration of inks used for printing expiration dates, batch codes on packaging in food, beverage, and pharmaceutical industries.
• Digital Printing & Proofing: Precision filtration of inks for wide-format graphics, textile digital printing, and commercial proofing.
• Office & Desktop Printing: Protective filtration for ink delivery systems in high-end office printers and plotters.
• Specialty Printing: Purification of functional inks used in 3D printing and printed electronics applications.
Ink Specific Capsule Filter - Engineered for Digital Printing & Ink Filtration
APPLICATIONS
• Industrial Marking & Coding: Filtration of inks used for printing expiration dates, batch codes on packaging in food, beverage, and pharmaceutical industries.
• Digital Printing & Proofing: Precision filtration of inks for wide-format graphics, textile digital printing, and commercial proofing.
• Office & Desktop Printing: Protective filtration for ink delivery systems in high-end office printers and plotters.
• Specialty Printing: Purification of functional inks used in 3D printing and printed electronics applications.
• Precision Media Formulation:
Scientifically combines PP, Nylon, PES, and PTFE media to optimize compatibility and filtration performance for different ink bases (solvent/water-based/UV).
• Superior Cleanliness Assurance:
A non-fiber releasing construction eliminates the risk of printhead clogging or print defects caused by media migration.
• Flexible Connection Options:
Multiple standard end connections allow for easy integration into various inkjet printers, digital presses, and ink supply systems.
• High-Efficiency Filtration:
An optimized gradient structure provides high dirt holding capacity and consistent particle retention while maintaining good flow rates, extending service intervals.
• Broad Application Range:
Suitable for filtering pigments, dyes, and specialty inks used in continuous inkjet and drop-on-demand printing technologies.
MATERIALS OF CONSTRUCTION
| Filter Media | PP /Nylon/PES/PTFE |
| Cage & Support & End Caps | PP |
| Drainage | PP |
CHARACTERS
| Removal Ratings(μm) | 0.2,0.45,0.65,1.0,3.0,5.0,7.0,10,20,30,50 |
• Precision Media Formulation:
Scientifically combines PP, Nylon, PES, and PTFE media to optimize compatibility and filtration performance for different ink bases (solvent/water-based/UV).
• Superior Cleanliness Assurance:
A non-fiber releasing construction eliminates the risk of printhead clogging or print defects caused by media migration.
• Flexible Connection Options:
Multiple standard end connections allow for easy integration into various inkjet printers, digital presses, and ink supply systems.
• High-Efficiency Filtration:
An optimized gradient structure provides high dirt holding capacity and consistent particle retention while maintaining good flow rates, extending service intervals.
• Broad Application Range:
Suitable for filtering pigments, dyes, and specialty inks used in continuous inkjet and drop-on-demand printing technologies.
MATERIALS OF CONSTRUCTION
| Filter Media | PP /Nylon/PES/PTFE |
| Cage & Support & End Caps | PP |
| Drainage | PP |
CHARACTERS
| Removal Ratings(μm) | 0.2,0.45,0.65,1.0,3.0,5.0,7.0,10,20,30,50 |
| SERIES | MATERIAL | RATING(μm) | SIZE | SEAL | CONNECTION |
| Phamarmical | PP | 0.1μm | 2.5 | No | 1/4〞NPT With 6-9mm pagoda adapter |
| Laboratory | MCE | 0.22μm | 5 | Silicone | 1/2〞NPT |
| Electronics | Nylon | 0.45μm | 10 | EPDM | 3/8〞NPT |
| PES | 0.65μm | 85 | |||
| PTFE | 1.0μm | ||||
| Hydrophilic PTFE | 3.0μm | ||||
| PVDF | 10μm | ||||
| Hydrophilic PVDF | 0.22+0.22μm | ||||
| GF | 0.22+0.45μm |
| SERIES | MATERIAL | RATING(μm) | LENGTH(in) | SEAL | SUPPORT |
| D-HFA | PP | 0.45μm | 20'' | Silicone | PP |
| GF | 1.0μm | 30'' | EPDM | GF | |
| PBT | 5.0μm | 40'' | Butyronitrile | PBT | |
| 304 | 10μm | 60'' | Viton | Outer Cage | |
| 316L | |||||
| SERIES | MATERIAL | RATING(μm) | LENGTH(in) | SEAL | SUPPORT |
| D-HFA | PP | 0.45μm | 20'' | Silicone | PP |
| GF | 1.0μm | 30'' | EPDM | GF | |
| PBT | 5.0μm | 40'' | Butyronitrile | PBT | |
| 304 | 10μm | 60'' | Viton | Outer Cage | |
| 316L |
| SERIES | MATERIAL | RATING(μm) | LENGTH(in) | SEAL | SUPPORT |
| HFA | PP | 0.45μm | 20'' | Silicone | PP |
| GF | 1.0μm | 30'' | EPDM | GF | |
| PBT | 5.0μm | 40'' | Butyronitrile | PBT | |
| 304 | 10μm | 60'' | Viton | Outer Cage | |
| 316L |
| SERIES | MATERIAL | RATING(μm) | SIZE | SEAL | CONNECTION |
| Phamarmical | PP | 0.1μm | 2.5 | No | 1/4〞NPT With 6-9mm pagoda adapter |
| Laboratory | MCE | 0.22μm | 5 | Silicone | 1/2〞NPT |
| Electronics | Nylon | 0.45μm | 10 | EPDM | 3/8〞NPT |
| PES | 0.65μm | 85 | |||
| PTFE | 1.0μm | ||||
| Hydrophilic PTFE | 3.0μm | ||||
| PVDF | 10μm | ||||
| Hydrophilic PVDF | 0.22+0.22μm | ||||
| GF | 0.22+0.45μm |
| SERIES | MATERIAL | RATING(μm) | LENGTH(in) | SEAL | SUPPORT |
| D-HFA | PP | 0.45μm | 20'' | Silicone | PP |
| GF | 1.0μm | 30'' | EPDM | GF | |
| PBT | 5.0μm | 40'' | Butyronitrile | PBT | |
| 304 | 10μm | 60'' | Viton | Outer Cage | |
| 316L | |||||
| SERIES | MATERIAL | RATING(μm) | LENGTH(in) | SEAL | SUPPORT |
| D-HFA | PP | 0.45μm | 20'' | Silicone | PP |
| GF | 1.0μm | 30'' | EPDM | GF | |
| PBT | 5.0μm | 40'' | Butyronitrile | PBT | |
| 304 | 10μm | 60'' | Viton | Outer Cage | |
| 316L |
| SERIES | MATERIAL | RATING(μm) | LENGTH(in) | SEAL | SUPPORT |
| HFA | PP | 0.45μm | 20'' | Silicone | PP |
| GF | 1.0μm | 30'' | EPDM | GF | |
| PBT | 5.0μm | 40'' | Butyronitrile | PBT | |
| 304 | 10μm | 60'' | Viton | Outer Cage | |
| 316L |
