The correct micron rating depends on the particle size to be removed, required downstream cleanliness, contamination load, flow rate, and the role of the cartridge in the filtration system. Available ratings range from 1 to 100 μm, allowing selection for both finer particle removal and broader prefiltration duties.

Its large-format construction is designed to handle higher liquid flow rates while maintaining stable filtration performance. Compared with conventional small-diameter cartridges, a high flow filter can help simplify system design by processing more liquid per cartridge, depending on the actual operating conditions and required filtration rating.

Compatibility depends on the fluid composition, chemical concentration, operating temperature, contact time, and actual process conditions. The cartridge uses polypropylene filter media and a polypropylene cage, making it suitable for many general industrial liquids, but chemical compatibility should be confirmed before use with aggressive chemicals or unusual process fluids.

The listed maximum operating temperature is 80°C, and the maximum differential pressure is 2.5 bar at 20°C. Actual allowable conditions should also consider fluid properties, filtration rating, flow rate, and system configuration. Temperature and differential pressure should always be evaluated together before final selection.

Compatibility should be checked according to cartridge outer diameter, length, sealing interface, flow direction, and housing dimensions. The listed cartridge sizes include 20", 40", and 60" lengths with outer diameters of approximately 158–160 mm. Providing your current cartridge model or housing dimensions is the most reliable way to confirm fit.
