A capsule filter is an integrated filtration device that uses a pleated membrane design to increase the filtration surface area, suitable for large-volume solution and gas filtration needs in laboratories and industrial settings. Its shell is generally made of polypropylene, free of adhesives or surfactants, to avoid sample contamination. Different types of membranes can be used in various fields to simplify operating procedures and reduce leakage risks.
It is mainly used in biopharmaceuticals (vaccine, antibiotic filtration), food and beverage (beer purification), electronics industry (photoresist filtration), chemical industry (ink processing), and laboratory settings, covering various process stages such as sterilization filtration, particle retention, and high-purity liquid treatment.
This article aims to briefly analyze the characteristics and application scenarios of capsule filter cartridges made of five different membrane materials, providing a selection guide for users.
✅Characteristics:
Resistant to acid, alkali, and organic solvent corrosion, suitable for highly corrosive liquid filtration environments.
Its high strength allows it to maintain structural integrity even under high pressure.
It is non-toxic, does not shed fibers during filtration, has good air permeability, temperature resistance, large filtration capacity, and high dirt-holding capacity.
✅ Typical Applications:
Process water in the electronics manufacturing industry
Pre-treatment in food and beverage production
✅ Characteristics:
Asymmetric sulfonated polyethersulfone material with a gradient pore structure that is small in the center and large at the edges.
Chemical resistance to strong acid and alkali environments.
Sterilization adaptability: Withstands online sterilization at 121℃ for 30 minutes
High heat resistance
✅ Typical Applications:
Medical equipment filtration systems
Pharmaceutical process fluid handling
High-purity water preparation systems
✅ Characteristics:
High chemical and thermal stability
Resistant to strong acids, strong alkalis, and organic solvents
High mechanical strength and tear resistance
✅ Typical Applications:
Semiconductor manufacturing processes
Corrosive chemical handling
High-temperature filtration systems
✅Characteristics:
Naturally hydrophilic, filters water-based solutions without pre-wetting
Resistant to appropriate concentrations of acid and alkali solutions
High mechanical strength and tear resistance
✅ Typical Applications:
High-pressure liquid filtration
Bio-separation processes
Food & beverage processing
Specialty chemical treatment
✅Characteristics:
High-temperature stability: Maintains stable filtration performance under high-temperature environments
Corrosion Resistance: Adaptable to various chemical environments
✅ Typical Applications:
High-Temperature Gas Filtration
Precision Particulate Removal
Oil-Water Separation Systems
To more intuitively demonstrate the performance characteristics of each material, the following is a detailed comparative analysis table
| Feature | PP | PES | PVDF | Nylon | GF |
| Cost Efficiency | ✅✅✅ | ✅✅ | ✅ | ✅✅ | ✅ |
| Biocompatibility | Fair | ✅✅✅ | Fair | Good | Fair |
| Chemical Resistance | Good | Fair | ✅✅✅ | Good | ✅✅✅ |
| Mechanical Strength | Good | Good | Good | ✅✅✅ | ✅✅✅ |
| Thermal Stability | Fair | Good | ✅✅✅ | Fair | ✅✅✅ |
| Adsorption Tendency | Low | Low | Low | Medium | Low |
| Temp. Range (°C) | 1–80 | 1–95 | 1–95 | 1–95 | 1–95 |
| pH Range | 1–14 | 1–14 | 1–12 | 1–14 | 1–14 |
Industry-Specific Recommendations:
Pharmaceuticals: Prioritize PES material to ensure biocompatibility and regulatory compliance
Food & Beverage: Choose PP or PES material to meet food safety requirements
Chemical Processing:Select PVDF or GF material based on fluid characteristics
Electronics:Use PES or Nylon material to ensure high purity requirements
LOONG Filtration has been a mission-driven partner, engineering high-performance fluid and gas filtration solutions for critical industries like chemical, food & beverage, biopharma, and electronics.
Bactericidal Filtration of SVP
Bacteria-Reducing and Bacteria-Removing Filtration of Medical Purified Water
Filtration of Flow Cytometer Sheath Fluid, Immunoanalyzer Liquid Path, Biological Products, Buffer, Feed Liquid
Filtration of Serums, Peptides, Cell Products, Diagnostic Reagents ,Immunoanalyzer Liquid Path
Capsule filters, as key components for filtering and separating contaminants, play a vital role in various industrial and application fields. They are indispensable in maintaining production quality, improving equipment performance, and ensuring environmental health and safety.
